Logic Gates
Wire gates into adders, flip-flops and memory.
Also on your phone · Logic Gates
The course
5 worlds · 38 lessons
World 1 · Gate Fundamentals
FREEThe seven building blocks of every digital circuit- 01Bits, Signals & Truth TablesEverything a computer does is 1s and 0s · 5 min
- 02The AND GateOutput 1 only when every input is 1 · 6 min
- 03The OR GateOutput 1 when at least one input is 1 · 6 min
- 04The NOT Gate (Inverter)Flip the bit · 5 min
- 05The XOR GateOutput 1 when inputs differ · 6 min
- 06NAND — the Universal GateAND, then invert · 6 min
- 07NOR & XNORThe other two inverted gates · 6 min
- 08De Morgan’s LawsTurning ANDs into ORs · 7 min
- 09Gate RoundupAll seven gates, side by side · 5 min
World 2 · Combinational Circuits
PROAdders, multiplexers and comparators from raw gates- 01The Half AdderAdd two bits: Sum + Carry · 8 minPRO
- 02The Full AdderAdd three bits with a carry-in · 10 minPRO
- 03Multi-bit AdditionChaining adders into a ripple-carry adder · 7 minPRO
- 04The 2:1 MultiplexerA data selector — pick input A or B · 9 minPRO
- 05DecodersTurn a binary code into one-hot lines · 7 minPRO
- 06The 1-bit ComparatorAre two bits equal? · 6 minPRO
- 07Boolean AlgebraSimplify before you build · 8 minPRO
- 08Karnaugh MapsA visual way to minimise logic · 9 minPRO
- 09Design ReviewFrom spec to gates · 5 minPRO
World 3 · Sequential Foundations
PROCircuits that remember — latches, flip-flops and counters- 01Combinational vs. SequentialAdding memory to logic · 6 minPRO
- 02The SR LatchThe simplest 1-bit memory · 8 minPRO
- 03The Gated D LatchStore a bit only when enabled · 7 minPRO
- 04The D Flip-FlopCapture on the clock edge · 8 minPRO
- 05RegistersStore a whole number · 6 minPRO
- 06Binary CountingHow lamps count 0–15 · 7 minPRO
- 07The Ripple CounterFlip-flops that toggle each other · 7 minPRO
- 08Clocks & TimingKeeping everything in step · 6 minPRO
World 4 · Build Projects
PROAssemble real machines from the gates you know- 01From Gates to MachinesHow the projects fit together · 5 minPRO
- 02Project: Majority VoteOutput 1 when 2 of 3 agree · 9 minPRO
- 03Project: 4-bit AdderChain four full adders · 12 minPRO
- 04Project: Binary → DecimalDecode 4 bits to a digit · 8 minPRO
- 05Project: Traffic LightA state machine in gates · 10 minPRO
- 06Project: 1-bit ALUAdd or AND, chosen by a control bit · 11 minPRO
- 07Project: Parity CheckerError detection with XOR · 7 minPRO
- 08Where Logic Goes NextFrom gates to CPUs and code · 5 minPRO
World 5 · Algorithms Visualized
PROSorting, graph search, trees, and from gates to a CPU- 01Sorting race: insertion vs mergeCounting comparisons, n² against n·log n · 10 minPRO
- 02Shortest path: BFS vs DFSBreadth first finds the shortest route; depth first may not · 10 minPRO
- 03Build the shortest search treeInsertion order decides a binary search tree’s height · 10 minPRO
- 04From gates to a CPU: run 3 + 4Fetch, decode, execute on a 4-instruction toy CPU · 10 minPRO
